Motorcraft CX-2409 Vapor Canister Purge Valve — Complete Fix for Ford P0443 & P0496 EVAP Codes
If your Ford F-150, Explorer, Mustang, or Edge is showing a P0443 or P0496 check engine light, the vapor canister purge valve is almost always the cause. The Motorcraft CX-2409 is the genuine OEM purge valve for a wide range of 2010–2021 Ford and Lincoln vehicles — and in this guide we'll explain exactly what it does, how to diagnose a failed one, and how to replace it yourself in under 10 minutes.
What is the vapor canister purge valve?
Your Ford's EVAP (evaporative emission control) system prevents raw fuel vapors from escaping into the atmosphere. Instead, fuel vapors from the gas tank are stored in a charcoal canister and then routed back into the engine to be burned during normal operation. The purge valve — also called the canister purge solenoid — controls when and how much vapor is released from the canister into the intake manifold.
When the purge valve fails stuck open or stuck closed, the EVAP system can't function correctly. This triggers a check engine light and can cause a range of drivability issues.
Symptoms of a failing CX-2409 purge valve
Check engine light with codes P0443 (EVAP purge control valve circuit) or P0496 (EVAP flow during non-purge)
Rough idle — especially after filling the fuel tank
Hard starting right after fueling
poor fuel economy
Strong fuel smell from the engine bay
Failed emissions test
P0443 and P0496 are among the most common check engine codes on Ford vehicles equipped with the CX-2409 purge valve. In most cases, replacing the purge valve with the correct Motorcraft unit clears the code immediately and resolves all symptoms.
Why genuine Motorcraft CX-2409?
OEM Ford Part No: AU5Z-9C915-B — engineered to Ford factory specifications
Direct plug-and-play replacement — OE connector, no cutting or splicing required
Sealed valve design built to OEM specifications for reliable, long-lasting performance
Motorcraft 2-year / unlimited mile warranty — valid at any Ford or Lincoln dealer
Aftermarket purge valves often fail prematurely or don't fully resolve EVAP codes
Vehicle compatibility
2011–2021 Ford F-150 5.0L & 3.5L
2013–2019 Ford F-250/F-350 Super Duty 6.2L
2011–2019 Ford Explorer 3.5L
2011–2018 Ford Edge 3.5L
2011–2017 Ford Mustang 5.0L
2010–2019 Ford Fusion 2.5L
2013–2019 Ford Flex 3.5L
2013–2019 Ford Taurus 3.5L
2009–2019 Ford Escape 2.5L
2010–2021 Ford E-350 & Transit
2011–2019 Lincoln MKX, MKZ, MKS, MKT
2017–2020 Lincoln Continental
Cross references: CX-2409, AU5Z-9C915-B, AU5Z9C915A, 911-222, CP758, CX2383. Please verify fitment with your VIN before ordering.
How to replace the CX-2409 purge valve — under 10 minutes
Let the engine cool before starting
Locate the purge valve on the intake manifold — usually near the throttle body
Disconnect the vacuum hose from the purge valve
Unplug the electrical connector — press the tab and pull
Remove the mounting bolt or clip holding the valve in place
Install the new CX-2409 in reverse order
Reconnect the vacuum hose and electrical connector
Clear the EVAP code with an OBD-II scanner and test drive
The code may take up to 50–100 miles of driving to clear on its own if you don't have a scanner. With a scanner, it clears instantly after replacement.
🎥 Every order from SayParts includes a FREE step-by-step installation video covering the complete CX-2409 replacement on your Ford — no special tools required.
Why buy from SayParts?
Genuine Motorcraft CX-2409 with 2-year / unlimited mile Ford warranty
Free installation video — replace it yourself in under 10 minutes
Free worldwide shipping
VIN verification available — contact us before ordering if unsure about fitment
Don't let an EVAP code fail your emissions test or leave your Ford running rough. The Motorcraft CX-2409 is the correct OEM purge valve — and it's one of the easiest fixes you can do yourself.
👉 Order the Motorcraft CX-2409 at SayParts: https://sayparts.com/products/motorcraft-cx-2409-vapor-canister-purge-valve-ford-f150-explorer-mustang-2010-2021
Fits 2010–2021 Ford F-150, F-250, F-350, Explorer, Edge, Mustang, Fusion, Flex, Taurus, Escape, E-350, Transit and Lincoln MKX, MKZ, MKS, MKT, Continental. Verify fitment with VIN before ordering.
